Polymer & Duty Gear Engraving Styles

Grip and duty-gear textures are the least decorative and most demanding thing a laser does. The pattern has to survive being gripped with wet or gloved hands, stay legible after finishing, and hold its geometry when it wraps a curved panel rather than a flat test coupon. These styles cover stipple grades, checkering, tread, knurl, serrations, hex and mesh fields, plus the surfaces duty gear is actually made of — strap webbing, sprayed splatter finish and thermoformed pebble grain. They are the patterns people cut into firearm grips and magazines, holsters, tool handles, tumblers and knife scales. Density matters more here than in any other family: too fine and the texture fills in on a second pass, too coarse and it stops functioning as grip.

Materials these styles are tuned for: firearms, leather, metal, polymer, tumblers, wood.

16 styles in this family

Aggressive Stippling — Coarse bold crater stipple for deep-cut grip. Best for firearms, metal, wood. Use this style in The Fabricator
Diamond Checkering — Sharp 1911/rifle-stock diamond-point checkering grid. Best for metal, wood. Use this style in The Fabricator
Golf Ball Dimple — Uniform grid of shallow concave golf-ball dimples. Best for metal, wood. Use this style in The Fabricator
Grip Tape — Coarse skateboard grip-tape grit, non-slip texture. Best for wood, metal. Use this style in The Fabricator
Guilloche Engine Turn — Machine-turned barleycorn moire - lathe-cut watch-dial texture Best for metal, tumblers. Use this style in The Fabricator
Hex Grip — Tightly packed hexagon honeycomb grip cells. Best for metal, wood. Use this style in The Fabricator
Holster Pebble — Thermoformed pebble grain packed shoulder to shoulder. Best for polymer, leather, metal. Use this style in The Fabricator
Knurling — Machined crosshatch diamond knurl, tool-handle texture. Best for metal, wood. Use this style in The Fabricator
MOLLE Webbing — Woven tactical strap grid with stitch lines and bar tacks. Best for polymer, metal, wood. Use this style in The Fabricator
Perforated Sheet — Staggered grid of solid punched round holes. Best for metal, tumblers, firearms. Use this style in The Fabricator
Slide Serrations — Bold parallel slide cocking-serration grooves. Best for metal, wood. Use this style in The Fabricator
Splatter Finish — Sprayed droplet splatter scattered across open ground. Best for polymer, metal, tumblers. Use this style in The Fabricator
Stippling — Aggressive Glock-style peened dot stipple, randomized organic scatter. Best for metal, wood. Use this style in The Fabricator
Tactical Stippling — Stipple inside hard-bordered geometric grip panels. Best for firearms, metal, wood. Use this style in The Fabricator
Tread Plate — Raised diamond traction tread plate, seamless tile. Best for metal, wood. Use this style in The Fabricator
Wire Mesh — Interlaced woven wire screen on a square grid. Best for metal, tumblers, firearms. Use this style in The Fabricator

Using these styles

Open the Fabricator, load the outline of the part you are engraving, and choose a style from this family. The pattern is generated to fill your outline rather than pasted over it, so the result fits the part instead of being cropped to it. Run a test on matching scrap before committing a production piece — density that reads perfectly on coated metal can close up on open-grain wood, and the fix is usually speed or an extra pass rather than more power.
