Free Rotary Centerline Template SVG
A simple centerline and wrap-boundary template for planning cylindrical artwork. Set the width from the measured circumference and verify rotary steps before engraving.
Specifications and context
- Format
- SVG
- Price
- Free
- Use
- Rotary layout alignment
- Works with
- Measured circumference and rotary setup
Production guidance
Use these parameters as a documented starting point, not a universal prescription. Material batches, optics, focus, air assist, source age, and machine calibration all affect the finished result. Confirm focus, protect the work area, and run a small test on matching scrap before committing a production piece. Record the date, material supplier, lens, focus method, and final parameter changes with the saved job so the result can be reproduced instead of rediscovered.
- 1. Measure the actual engraving circumference instead of relying only on a cup model name.
- 2. Use low-power framing or a wrapped paper test before the finished tumbler.
